Application Field
Aluminum foil: suitable for various aluminum foil bursting strength tests, and is a basic testing item for aluminum foil materials
Paper: suitable for testing the bursting strength of various paper materials
Cardboard: suitable for testing the bursting strength of various types of cardboard
Note: The test standards for paper, cardboard and aluminum foil are different, and the instrument indicators need to be determined according to the material
Test Criteria:
ISO 2759: Determination of bursting resistance of paperboard;
GB/T 1539: Determination of bursting resistance of paperboard;
QB/T 1057: Paper and cardboard bursting meter.
Product Features
Instrument with parameter testing, memory, printing and other functions.
High definition LCD display, automatic reset, automatic one-button operation, easy to operate,
KPa, kgf/cm, PSI and other international unit conversion, real-time curve analysis graph intelligence system.
In line with the latest national standards GB/T1539 and ISO2759:2001 international standards,
It is an ideal equipment for scientific research units, paper mills, packaging industries, and quality inspection departments.
Technical Parameters:
induction method | pressure converter |
display mode | High definition LCD display |
unit of strength | Kgf/cm2, Lb/in2, Kpa (unit switching function) |
Measuring range | 250~ 6000kPa |
resolution | 1kPa |
measurement accuracy | indication error | Better than ± 1% FS |
Indication variability | Better than ± 1% |
Oil pressure speed | High pressure 170 ± 10ml/min |
Film resistance | Raise 10mm, 170kPa~ 220kPa; Raise 18mm, 250kPa~ 350kPa |
Clamp ring material | stainless steel |
clamping force | > 690Kpa (adjustable) |
Inner diameter of upper clamp ring hole | φ (31.5 ± 0.05) mm |
Inner diameter of lower clamp ring hole | φ (31.5 ± 0.05) mm |
Upper chuck diameter: | 95Mm |
Lower chuck diameter: | 135Mm |
Hydraulic oil | silicone oil |
volume | 430 * 530 * 520Mm |
weight | About 70KG |
power supply | 1, AC220V |
Configuration:
Standard configuration: host, embedded micro printer, 5 pieces of rubber film, 1 wrench, 10 correction pieces, 1 bottle of silicone oil
Remarks: Pneumatic clamping type requires air source, and the air source and air source connector are provided by the user.
Remarks: Based on the upgrade needs of the product, the appearance of the product will change without notice. You can log in to www.jmlabtest.com for the latest information. The company reserves the right to modify and final interpretation.
