Technical Parameters
(1) Standard test force: 30N (other ranges are optional)
(2) Control mode: touch screen
(3) Operation mode: professional peeling measurement and control software
(4) Test method: 180 ° adhesive tape peeling
(5) Measurement range: 0.5% to 100% of the maximum test force
(6) Accuracy level: ± 0.5%
(7)Test force accuracy: ± 0.5% better than the indicated value
(8)Deformation display error: ≤ ± (50 + 0.15L)
(9)Test force: minimum resolution 0.001N
(10)Displacement measurement: resolution of 0.001mm
(11)Deformation accuracy: better than ± 0.5%
(12) LCD display content: test force, displacement, peak value, running state, running speed, etc
(13) Stepless speed regulation: using stepper motor and control system
(14) Drive mode: stepper motor, ball screw drive
(15)Motor power: 50W
(16)Speed range: 1mm/min~~ 500 mm/min
(17) Test stroke: 300mm (excluding fixture)
(18) Host size: 600 * 300 * 250mm
(19)Test protection function: overload protection, leakage protection, limit protection
Product Features
(1)The whole process of the test is controlled by the single-chip microcomputer and automatically returns to its original position.
(2) The electrical part includes a load measurement system and a deformation measurement system.
(3) With different fixtures, various tests can be performed, and the output of test results can be arbitrarily set: tensile strength, deformation rate, peel strength, and dynamic shear strength.
(4) With curve display, query and other functions.
(5)Equipped with different fixtures for different materials to facilitate test operation.
